MyConnect 150

SPECIFICATIONS
POWER OUTPUT 8Ω, 4Ω and 2,66Ω 130W, 190W and 250W CLASS AB
OUTPUT LEVEL Unbalanced (max volume) 9 volts
FREQUENCY RESPONSE (+/-3dB) 2 0Hz - 80 kHz
DISTORTION < 0.006% @1KHz/1W
SIGNAL TO NOISE HN 105dB
OUTPUT IMPEDANCE 10KΩ
CHANNEL SEPARATION > 110dB
DAC DIGITAL AUDIO AKM AK4490 (32bit - 768kHz)
DIGITAL AUDIO PCM TRANSCEIVER AK4118
INTERFACE DE RECEPTION USB/DSD
* Optical input supporting : 24bit - 96kHz PCM
* Coaxial input supporting : 24bit - 192kHz PCM
* USB audio PCM input supporting 24bit/32bit 44,1kHz - 384kHz
* USB audio PCM input supporting 2.8MHz (DSD64)-DOP/5.6MHz, (DSD128)-DOP/11.2MHz (DSD 256)-DOP
AC INPUT 115/230V 50/60Hz
TENSION SECTEUR
POWER CONSUMPTION MAX Max 900W
CONSOMMATION MAXIMALE
DIMENSIONS H. 170 x l. 371 x D. 430
NET WEIGHT 14,5 KG
Gross WEIGHT 17,2 KG
